New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter

New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter
New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter

큰 이미지 :  New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter

제품 상세 정보:
원래 장소: 지난, 중국
브랜드 이름: Sinotruck HOWO
모델 번호: zz41551N3846
결제 및 배송 조건:
최소 주문 수량: 단위 1 개
가격: USD 41200~46500 PER UNITS
포장 세부 사항: 나체상
배달 시간: 20~25 근무일
지불 조건: l/c, d/a, d/p, t/t
공급 능력: 주당 50 대

New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter

설명
탱크 볼륨: 15001-30000L 연료 유형: 디젤
상태: 새로운 마력: 251 - 350마력,351 - 450마력
저장: 기름, 물, LPG 엔진 용량: 9.726L
색상: 선택 과목 배출 표준: 유로2/3/4/5
강조하다:

SINOTRUK HOWO refueling truck with flow meter

,

10 Cbm fuel tank truck Euro2

,

10000L refueling truck with warranty

New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter

Product Name
SINOTRUK HOWO 4x2 Oil Tank Truck 20CBM
Chassis Model
ZZ1257N4341W
Driving Type
LHD (RHD is optional)

Cabin
HW76, with one sleeper and two seats, double arm windscreen wiper system with
three speeds, damped adjustable driver's seat, with heating and ventilating system,
exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner,
with transverse stabilizer, with four piont support floating suspension+shock absorber.
Engine
Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine
Engine model: WD615.47, Euro 2, 371 HP
6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Displacement: 9.726 L
Transmission
HW19710, 10F & 2R speeds , with PTO
Steering
ZF power steering, model ZF8118, hydraulic steering with power assistance
Front Axle
HF9,1x9000 KGS
Steering with double T-cross section beam
Rear Axle
HC16, 2x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with differential
locks between wheels and axles.
Ratio:4.8 / 5.73
Propeller Shaft
Double universal joint propeller shaft with gear-shaped coupling flange
Chassis
Frame: U-profile parallel ladder frame with section of 300x80x8mm,reinforced
Sub-frame all cold riveted cross members Front suspension:10 semi elliptic leaf
spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
Brake
Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on
front shaft and rear wheels
Auxiliary brake: engine exhaust brake
Electrics
Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 165 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres
295/80R22.5, tubeless tyres with one spare tyre, 12.00R20 radial tire for option
Fuel Tank
400L
Oil Tank Body
20 Cubic Meters, can be customized



New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 0

New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 1New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 2New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 3New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 4New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 5New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 6

Oil tank trucks, also known as mobile refueling trucks, computerized tax controlled refueling trucks, oil tanker

trucks, oil loading trucks, oil transport trucks, oil transport vehicles, edible oil transport vehicles, are vehicles

that transport and store petroleum derivatives (gasoline, diesel, crude oil, lubricants, coal tar and other oil

products).
Transportation medium: Suitable for transporting liquid substances such as alcohols, aldehydes, benzene,

ethers, etc. in gasoline, kerosene, diesel, vegetable oil, edible oil, heavy oil, coal tar, and non petroleum

products.
The tank body is made of high-quality 4-6 mm thick carbon steel national standard plates, which can be made

of carbon steel or stainless steel. Aluminum alloy, pure aluminum tanks, lined with rubber, plastic tanks, and

fiberglass tanks can also be used as needed;
Can types include square circular, elliptical, and circular;
Oil pumps include self priming pumps, gear pumps, and dual pumps;
Can be designed as a specialized chemical transportation vehicle;
It can be independently divided into warehouses and packaged with different types of oil products. It can achieve

pump in and pump out, self flow, optional flow meter, computer-controlled fuel dispenser, 15 meter refueling reel

(automatic return), and multiple anti wave partitions inside the tank, making the tank strong, stable in center of

gravity, and safe and stable in vehicle transportation.
All oil tank trucks can be designed as chemical trucks and various heating and insulation series tank bodies; All

oil tankers can be equipped with computer fuel dispensers; Wide range of tonnage selection for households to

meet user needs; There are multiple wave barriers inside the tank. By using high-pressure gas leak testing, the

tank body is characterized by high strength, stable center of gravity, and safe and stable vehicle transportation.

New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 7



New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 8New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 9New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 10New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 11New SINOTRUK HOWO 4*2 Euro2 10 Cbm 10000L Refueling Truck With Flow Meter 12
